Description
1 Ohm VERSION Nominal Power @12.6VDC
1 Ohm: 8000W RMS
2 Ohms: 4800W RMS
4 Ohms: N/A
Number of Channels 01
Input Sensitivity 0.22V 4V
Signal to Noise Ratio >90dB
Frequency Response 10Hz 10KHz (-3dB)
Crossover high pass (HPF) 10Hz 90Hz (-12dB/8 ) Variable
Crossover low pass (LPF) 90Hz 10KHz (-12dB/8 ) Variable
bass boost Freq.: 35Hz 55Hz
Boost: 0 +10dB
Efficiency 82%
Input Impedance 10K Ohms
Output Impedance 1 Ohm
protection system Short-Circuit to Output, Short on output compared to GND, Low impedance at output, High/Low supply voltage and Thermal protection.
Minimum Supply Voltage 9.5VDC
Maximum Supply Voltage 17VDC
Consumption at rest 2.90A
Maximum music consumption 387A
Maximum consumption in sinusoidal signal 774A
Dimensions (WxHxD) 8.98″ x 2.76″ x 17.5″ (228 x 70 x 446 mm)
Weight 12.3lb (5,60Kg)
