The MD 5000.1 was carefully designed with the latest technology, offering high performance and efficiency for various types of car audio systems. Its wide frequency response (10Hz 10KHz (-3dB), allows it to be used with subwoofers and woofers of different models. It is an amplifier classified as mono, that is, it has a channel with a maximum power of 5000 Watts RMS.
1 Ohm VERSION Nominal Power @12,6VDC
1 Ohm: 5000W RMS
2 Ohms: 3200W RMS
4 Ohms: N/A
Number of Channels 01
Input Sensitivity 220mV
Signal to Noise Ratio >90dB
Frequency Response 10Hz 10KHz (-3dB)
Crossover high pass (HPF) 10Hz 90Hz (-12dB/8 ) Variable
Crossover low pass (LPF) 90Hz 10KHz (-12dB/8 ) Variable
bass boost Freq.: 35Hz 55Hz
Boost: 0 10dB (50Hz)
Efficiency 81%
Input Impedance 15K Ohms
Output Impedance 1 Ohm
protection system Short-Circuit to Output, Short on output compared to GND, Low impedance at output, High/Low supply voltage and Thermal protection.
Minimum Supply Voltage 9VDC
Maximum Supply Voltage 16VDC
Consumption at rest 1.20A
Maximum music consumption 244.50A
Maximum consumption in sinusoidal signal 489A
Dimensions (WxHxD) 8.98″ x 2.76″ x 12.87″ (228 x 70 x 327mm)
Weight 9.28lb (4.22Kg)
